Side Stand On Electric Stacker 1.5 Ton American CURTIS Drive Control System

Side Stand On Electric Stacker 1.5 Ton American CURTIS Drive Control System

  • High Light

    Stand On Electric Stacker 1.5 Ton


    Electric Stacker 1.5 Ton CURTIS


    1.5 Ton Electric Stacker Drive Control

  • Drive Motor
  • Power Supply
  • Tyre Material
  • Steering Type
    Electronic Steering
  • Brake System
  • Brake Mode
    Lever Operation
  • Place of Origin
  • Brand Name
  • Certification
  • Model Number
  • Minimum Order Quantity
    1 SETS
  • Price
    USD2470.00 - USD4700.00
  • Packaging Details
  • Delivery Time
    10 WORK DAYS
  • Payment Terms
    L/C, T/T, D/A, D/P, Western Union
  • Supply Ability

Side Stand On Electric Stacker 1.5 Ton American CURTIS Drive Control System

1.5 Ton Automatic Deceleration of Bends Narrow Aisle Optional Fork Electric Spin Side Shift Pallet Stacker


  • Wide angle view, high-strength shock absorption gantry
  • American CURTIS brand drive control system
  • Minimum 1480mm stacking channel, special for narrow roadway
  • Electronic steering, portable, mute
  • multi function instrument, drive wheel position display
  • Electromagnetic and regenerative braking system
  • fork rotation angle 180 °, left and right side shift
  • Line fault detection error code diagnosis
  • 48V high capacity lead-acid battery
  • automatic alignment and guidance during walking



  • Curve automatic deceleration device
  • Automatic deceleration of fork in high cargo position
  • Drive stepless speed regulation
  • Controller multiple automatic protection system
  • Wireless monitoring system



LED headlights

Side pull battery

Cylinder safety shut-off valve

Optional fork electric rotation and side shift



Name   3-Way Pallet Stacker
Model   CSD15
Power type   Storage battery
Driving mode   Side stand-on type
Rated load kg 1500
Load center distance mm 500
Front overhang distance mm 665
wheelbase mm 1700
Vehicle weight (including battery) kg 4650
Tire type (drive side/ load side)   Polyurethane PU
Tire size (load-bearing side) mm Φ140×127
Tire size (drive side) mm Φ400×165
Number of wheels (front/ rear) (X= drive wheel)   4/1X
Track width (bearing side) mm 1280
Closing height of gantry mm 2565
Free lifting height mm 0
Lifting height mm 3000
Maximum height of gantry during lifting (including blocking rack) mm 4040
Height of roof protection frame mm 2260
Seat height mm 1070
Overall length mm 3000
Overall width mm 1550
Fork size mm 1070*125*50
Installation level   Class II type B
Outside distance of fork mm 400~780
Ground clearance of gantry mm 40
Stacking channel width (pallet 1000x1200) mm 1600
Turning radius mm 1850
Driving speed (full load/ no load) km/h 7.5/8
Lifting speed (full load/ no load) mm/s 180/315
Braking mode   Electromagnetic type
Drive motor power (S2-60min) kw 5.5 AC
Lifting motor power (S3-15%) kw 8.6 AC
Battery, voltage/ rated capacity v/ah 48/420
Battery weight kg 740
Steering system   Electronic steering
Battery replacement method   Side pull type
