1 Ton 2 Ton 1000 Kg 2000 Kg Electric Pallet Stacker USA Curtis Controller

1 Ton 2 Ton 1000 Kg 2000 Kg Electric Pallet Stacker USA Curtis Controller

  • High Light

    1 Ton Electric Pallet Stacker


    Curtis Controller Electric Pallet Stacker


    Lithium Battery Pallet Stacker

  • Cylinder
    Double Oil
  • Battery
    Lithium Battery
  • Braking Form
    Electromagnetic Braking
  • Power
  • Steering Form
    Electronic Steering
  • Battery Voltage
    48 - 80 V
  • Charging Time
    4 - 6 Hours
  • Model
    Electric Pallet Forklift
  • Operation Mode
    Stand-by Type
  • Power Source
  • Power Type
  • Tire Type
  • Colour
    Chinese Red
  • Place of Origin
  • Brand Name
  • Certification
  • Model Number
  • Minimum Order Quantity
    1 PC
  • Price
  • Packaging Details
  • Delivery Time
    10 WORK DAYS
  • Payment Terms
    L/C, T/T, D/A, D/P, Western Union
  • Supply Ability

1 Ton 2 Ton 1000 Kg 2000 Kg Electric Pallet Stacker USA Curtis Controller

Environment of Use:


Electric Pallet Stacker: Suitable for single sided pallets, cargo handling and stacking; Standard load capacity: 1000-3000kg, non-standard customized 3500-100000kg. The length of the 1-2 ton cargo fork is 1150mm, the outer width of the cargo fork is 685/560mm, the minimum ground clearance of the cargo fork is 90mm, the lifting height is 1600-600mm, and 3500-10000kg. Customized according to customer requirements. Pallet stackers are commonly used for stacking goods between shelves.



  • Drive stepless speed regulation
  • Controller multiple automatic protection system
  • Emergency reverse anti-collision/ emergency braking device

Design and manufacturer of intelligent storage equipment

Customized supplier of non-standard storage equipment

1 Ton 2 Ton 1000 Kg 2000 Kg Electric Pallet Stacker USA Curtis Controller 0

Product parameters:

Name   Electric pallet truck
Model   CBD10
Load kg 1000
Load center mm 600
Minimum ground clearance mm 90
Maximum ground clearance mm 200
Driving mode   Walking type
Overall width mm 780
Overall length mm 1790
Fork outer width mm 685/560
Maximum height of handle from the ground mm 1275
Turning Radius mm 1645
Fork size mm 1150*175*70
Right angle stacking channel (1200 x1000mm) mm 2425
Traveling speed (loaded/ unloaded) mm/s 3.5/4
Lifting motor (S3-15%) kw 0.8
Travel motor (S2-60min) kw 1.5
Braking form   Electromagnetic braking
Steering form   Mechanical steering
Body weight kg 600
Battery weight kg 200
Climbing gradient (full load/ no load) % 5/8
Battery capacity v/ah 210
Charger v/a 30
Number of tires (front/ rear) (X= drive wheel)   4/1X+2
Drive wheel mm Φ230*75
Bearing wheel mm Φ85*70
Auxiliary wheel mm Φ100 *50
Lifting speed (full load/ no load) mm/s 27/35
Falling speed (full load/ no load) mm/s 35/35
Tire type   Polyurethane
Battery replacement method   Lifting type


The company reserves the right to change the product design and planning, and the parameters are subject to change without notice
