Stand On Electric Pallet Stacker Pedestrian Reach Stacker 1500KG

Stand On Electric Pallet Stacker Pedestrian Reach Stacker 1500KG

  • High Light

    Stand On Electric Pallet Stacker

    ,

    Electric Pallet Stacker 1500KG

    ,

    Pedestrian Reach Stacker 1500KG

  • Power Type
    Battery
  • Tire Type
    Polyurethane
  • Mast Type
    Duplex Mast
  • Steering Type
    Electronic Steering
  • Parking Brake Type
    Electromagnetic Braking
  • Name
    Electric Pallet Stacker
  • Place of Origin
    ANHUI, CHINA
  • Brand Name
    YONGJIELI
  • Certification
    CE
  • Model Number
    CDD15-30
  • Minimum Order Quantity
    1 SETS
  • Price
    USD2470.00 - USD4700.00
  • Packaging Details
    EXPORT PACKING
  • Delivery Time
    10 WORK DAYS
  • Payment Terms
    L/C, T/T, D/A, D/P, Western Union
  • Supply Ability
    50 SETS PER MONTH

Stand On Electric Pallet Stacker Pedestrian Reach Stacker 1500KG

Rated Load 1500KG Electric Pedestrian Pallet Stacker Loading& Unloading Stacking & Short Distance Transportation

Model   CDD15-30 CDD25-30
Power type   Electric
Operation mode   Stand-on type
Rated load kg 1500 2500
Load center distance mm 500
Tire type (front/ rear)   Polyurethane
Number of tires   4/1X+2
Mast type   Duplex mast
Standard lifting height mm 3000
Free lifting height mm 0
Height of mast closed mm 2000
Height of mast open mm 3490
Min. ground clearance of fork mm 90
Overall length pedal (deployment/ retraction) mm 2515/ 2215 2525/2265
Wheelbase mm 1390
Overall width mm 850 850/12300
Track width (front/ rear) mm 490/604 505/1100
Fork specifications mm 1150*190*65 1150*205*65
Fork side outer distance mm 685/ 560 715
Turning radius pedal deployment/ retraction mm 2125/1715 2125/1720
Travel speed (full load/ no load) km/h 4.8/5.0 4.0/5.0
Lifting speed (full load/ no load) mm/s 100/150 80/125
Descent speed (full load/ no load) mm/s 150/105 160/105
Gradient (full load/ no load) % 6/ 8 5/ 8
Drive motor type   AC
Drive motor power kw 1.5 2.2
Type of lifting motor   DC
Lifting motor power kw 2.2 3
Battery voltage/ capacity v/ah 24/210
Battery weight kg 200
Vehicle weight (including battery) kg 1270 1300
Steering type   Electronic steering
Parking brake type   Electromagnetism
Parking brake operation mode   Handle operation
