        Advantages of Double-Reach Forklifts
Higher Storage Efficiency
Double-reach forklifts can operate in double-deep racking systems, allowing two pallet rows per rack and significantly increasing storage density. Ideal for high-turnover goods, reducing wasted storage space.
Greater Flexibility
Suitable for various warehouse layouts, especially those requiring high-density storage.
Lower Operating Costs
Stores more goods in the same warehouse area, reducing storage costs per unit.
Fewer Aisles Required
Double-depth storage reduces the number of aisles needed, saving warehouse space.
Increased Operational Complexity
Requires higher precision; operators may need additional training.
Accessing rear pallets requires moving the front ones first, increasing handling time.
Higher Equipment Costs
Initial purchase and maintenance costs are typically higher than single-reach forklifts.
Limited Applicability
Less suitable for scenarios requiring frequent access to individual pallets, particularly those stored at the rear.
Product Parameter
| Model | CSD15 | |
| Rated load | kg | 1500 |
| Maximum lifting height | mm | 7000 |
| Load center | 500 | |
| Tire configuration | Polyurethane wheel | |
| Operation mode | Seated type | |
| Mast tilt angle | 2/4 | |
| Fork size | mm | 1220*120*40 |
| Fork adjustment range | mm | 260-720 |
| Mast forward movement distance | mm | 550 |
| Mast type | Triplex full free mast | |
| Overall length | mm | 2480 |
| Overall width | mm | 1100 |
| Height of mast | mm | 2655 |
| Max. height of fork lifting (including gear rack) | mm | 6985 |
| Turning radius | mm | 1755 |
| Height of roof protection frame | mm | 2210 |
| Minimum stacking channel | mm | 2850 (1000*1000mm pallet) |
| Minimum ground clearance | mm | 70 |
| Maximum driving speed | km/h | 4.0/5.0 |
| Rising speed | mm/s | 90/140 |
| Gradeability | % | ≤5 |
| Total weight | kg | 2900 |
| Drive wheel | mm | 230*90 |
| Front wheel | mm | 210*85 |
| Auxiliary wheel | mm | 150*50 |
| Battery voltage/ capacity | v/ah | 24/280 |
| Lithium battery charger | v/ah | 24/40 |
| Lifting motor | kw | 3.0 |
| Drive motor | kw | 2.2 |
| Travel speed regulation mode | Hall accelerator | |
| Braking mode | Electromagnetic braking | |
| Steering mode | Electric steering |
FAQ:
Q1: Are you electric forklift factory?
A1: Yes, we are the new which means has Novel manufacturer and  professional produce of electric forklift for more than
10 years.

Q2: How about the delivery time?
A2: About 20-30 days based on different model.
For some standard products, we may have stock and could delivery immediately.

Q3: Is customized solution available?
A3: Yes, we can provide different customized solution.

Q4: Can you provide OEM and ODM service?
A4: Yes. We can do it .
