Electric Large Tonnage Towing  Tractor 20000 KG

Electric Large Tonnage Towing Tractor 20000 KG

  • Place of Origin
    ANHUI
  • Brand Name
    YONGJIELI
  • Certification
    CE
  • Model Number
    QDD-E
  • Minimum Order Quantity
    1 SET
  • Price
    USD12100.00
  • Packaging Details
    BULK OR CONTAINER
  • Delivery Time
    30 WORK DAYS
  • Payment Terms
    L/C, D/A, T/T, Western Union
  • Supply Ability
    30 SETS/ MONTH

Electric Large Tonnage Towing Tractor 20000 KG

Product parameter



驱动方式 Type of power

铅酸电池

Lead-acid battery

驾驶方式 Driving type   步行式Walkie type
额定牵引重量 Pated traction capacit) Q(kg) 20000
总长 Overall length L1(mm) 2270
总宽 Overall width b1(mm) 1060
总高 Overall height h11(mm) 1235
牵引座高度 Height of traction base h10(mm) 305/325/345
操作手柄高度 Height of operating handle b11(mm) 1380
整车离地间隙 Height of vehicle off the ground (min) m(mm) 118
蓄电池,电压/额定容量 Battery,voltage/capacity V/Ah 36V/240A
电池重量 Weight of battery kg 216
整车重量(含电池) Vehicle weight (including battery) kg 2170
驱动电机功率(S2-60min) Driving Motor Power (S2-60MIN) KW 36V/4KW
轮胎 Tire 橡胶实心轮胎     Rubber solid tire
轮子尺寸,前轮 Wheel dimensions,front wheel   3.50-5
轮子尺寸,后轮 Wheel dimensions,rear wheel   4.00-8
轮子,前后数量(x=驱动轮) Number of wheels,front and rear(x=driving wheel)   2/2x
后轮轮距 Rear wheel track b10(mm) 907
轴距 Wheelbase y(mm) 1060
转弯半径 Turn radius Wa(mm) 1370
轴负载,空载前/后 Axle full load,/no load front/rear kg 443/1727
行驶速度,满载/空载 Driving speed,full load/no load Km/h 2.5/4.0
爬坡能力,满载/空载(S2-5min) Maximum climb,full load/no load (S2-5MIN) 9% 2.0/12.0
制动方式 Braking type 电磁制动Electromagnetic brake

Electric Large Tonnage Towing  Tractor 20000 KG 0Electric Large Tonnage Towing  Tractor 20000 KG 1



本公司保留更改产品设计和规格的权利,参数若有改变,恕不另行通知

The companyreserves the right to change product design andspecifications.Parameters are subject to change without prior notice
