Customization Pallet Stacker Forklift Truck Rated Capacity 3000 KGS Lifting Height 3000mm Fork Length 1150mm

Customization Pallet Stacker Forklift Truck Rated Capacity 3000 KGS Lifting Height 3000mm Fork Length 1150mm

  • High Light

    3000kg Pallet Stacker Forklift Truck

    ,

    Customization Pallet Stacker Forklift Truck

    ,

    3000mm Fork Electric Reach Truck Forklift

  • Place of Origin
    ANHUI, CHINA
  • Brand Name
    YONGJIELI
  • Certification
    CE
  • Model Number
    CDD30
  • Minimum Order Quantity
    1 SETS
  • Price
    USD2470.00 - USD4700.00
  • Packaging Details
    EXPORT PACKING
  • Delivery Time
    10 WORK DAYS
  • Payment Terms
    L/C, T/T, D/A, D/P, Western Union
  • Supply Ability
    50 SETS PER MONTH

Customization Pallet Stacker Forklift Truck Rated Capacity 3000 KGS Lifting Height 3000mm Fork Length 1150mm

 More  Specification :



Pallet stacker truck

Rated load capacity: 3000kg

Lifting height: 3000mm

Fork outer width: 750mm

Fork length: 1150mm

Lithium battery: 25.6V200AH

Electronic steering pedal protection arm



Safety:

  • Curve automatic deceleration device
  • Automatic deceleration of fork in high cargo position
  • Drive stepless speed regulation
  • Controller multiple automatic protection system
  • Emergency reverse anti-collision/ emergency braking device
  • Cylinder safety shut-off valve
Model   CDD30
Power type   Electric
Operation mode   Stand-on type
Rated load kg 3000
Load center distance mm 500
Tire type (front/ rear)   Polyurethane
Number of tires   4/1X+2
Mast type   Duplex mast
Standard lifting height mm 3000
Free lifting height mm 0
Height of mast closed mm 2000
Height of mast open mm 3490
Min. ground clearance of fork mm 90
Overall length pedal (deployment/ retraction) mm 2515/ 2215
Wheelbase mm 1390
Overall width mm 850
Track width (front/ rear) mm 490/604
Fork specifications mm 1150*190*65
Fork side outer distance mm 685/ 560
Turning radius pedal deployment/ retraction mm 2125/1715
Travel speed (full load/ no load) km/h 4.8/5.0
Lifting speed (full load/ no load) mm/s 100/150
Descent speed (full load/ no load) mm/s 150/105
Gradient (full load/ no load) % 6/8
Drive motor type   AC
Drive motor power kw 1.5
Type of lifting motor   DC
Lifting motor power kw 2.2
Battery voltage/ capacity v/ah 24/210
Battery weight kg 200
Vehicle weight (including battery) kg 1270
Steering type   Electronic steering
Parking brake type   Electromagnetism
Parking brake operation mode   Handle operation
