4.0 Ton Electric Vehicle Mover Curtis Electronic Control CE

4.0 Ton Electric Vehicle Mover Curtis Electronic Control CE

  • High Light

    4.0 Ton Electric Vehicle Mover

    ,

    Electric Vehicle Mover Curtis Control

  • Drive Motor
    AC
  • Power Supply
    Battery
  • Tyre Material
    Polyurethane
  • Steering Type
    Electronic Steering
  • Brake System
    Electromagnetic
  • Brake Mode
    Lever Operation
  • Place of Origin
    ANHUI, CHINA
  • Brand Name
    YONGJIELI
  • Certification
    CE
  • Model Number
    QDD40A
  • Minimum Order Quantity
    1 SETS
  • Price
    USD2470.00 - USD4700.00
  • Packaging Details
    EXPORT PACKING
  • Delivery Time
    10 WORK DAYS
  • Payment Terms
    L/C, T/T, D/A, D/P, Western Union
  • Supply Ability
    50 SETS PER MONTH

4.0 Ton Electric Vehicle Mover Curtis Electronic Control CE

Provide non-standard Customization Electric Tow Tractor Traction Weight 4.0 Ton Electronic Power Steering Portable



Product parameters:

Model   QDD40A
Operation type   Stand-on type
Power type   Battery
Tire configuration   Polyurethane solid tire
Max. towing weight kg 4000
Max. traction KN 1250
Overall height mm 1600
Width mm 776
Length mm 1330
Max. driving speed km/h 4/5.5
Wheelbase mm 955
Battery weight kg 190
Turning radius mm 1180
Parking brake type   Electromagnetic braking
Total weight kg ~550
Front wheel mm Φ230*75
Rear wheel mm Φ150*50
Battery voltage/ capacity v/ah 24V/210
Drive motor kw 1.5
Travel speed regulation mode   Hall accelerator
Electronic control   Curtis electric control
Battery replacement method   Lifting type
