4.0 Ton Electric Vehicle Mover
,Electric Vehicle Mover Curtis Control
-
Drive MotorAC
-
Power SupplyBattery
-
Tyre MaterialPolyurethane
-
Steering TypeElectronic Steering
-
Brake SystemElectromagnetic
-
Brake ModeLever Operation
-
Place of OriginANHUI, CHINA
-
Brand NameYONGJIELI
-
CertificationCE
-
Model NumberQDD40A
-
Minimum Order Quantity1 SETS
-
PriceUSD2470.00 - USD4700.00
-
Packaging DetailsEXPORT PACKING
-
Delivery Time10 WORK DAYS
-
Payment TermsL/C, T/T, D/A, D/P, Western Union
-
Supply Ability50 SETS PER MONTH
4.0 Ton Electric Vehicle Mover Curtis Electronic Control CE
Provide non-standard Customization Electric Tow Tractor Traction Weight 4.0 Ton Electronic Power Steering Portable
Product parameters:
| Model | QDD40A | |
| Operation type | Stand-on type | |
| Power type | Battery | |
| Tire configuration | Polyurethane solid tire | |
| Max. towing weight | kg | 4000 |
| Max. traction | KN | 1250 |
| Overall height | mm | 1600 |
| Width | mm | 776 |
| Length | mm | 1330 |
| Max. driving speed | km/h | 4/5.5 |
| Wheelbase | mm | 955 |
| Battery weight | kg | 190 |
| Turning radius | mm | 1180 |
| Parking brake type | Electromagnetic braking | |
| Total weight | kg | ~550 |
| Front wheel | mm | Φ230*75 |
| Rear wheel | mm | Φ150*50 |
| Battery voltage/ capacity | v/ah | 24V/210 |
| Drive motor | kw | 1.5 |
| Travel speed regulation mode | Hall accelerator | |
| Electronic control | Curtis electric control | |
| Battery replacement method | Lifting type |
